| Artikelnummer | LC420WUF-SBN1 |
| Marke | LG Display |
| Größe | 42 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 1400:1 |
| Farben | 16.7M/1.06B |
| Hintergrundbeleuchtung | EEFL |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LC420WUF-SBN1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 42 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | S-IPS, Normally Black, Transmissive |
| aktiver Bereich | 930.24×523.26 mm |
| Umriss | 965.2×558.2 mm |
| Oberfläche | Antiglare (Haze 10%), Hard coating (3H) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 1400:1 (Typ.) |
| Farben anzeigen | 16.7M/1.06B (8-bit / 8-bit + Dithering) |
| Reaktionszeit | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) |
| Blickwinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampentyp | 18 pcsEEFLWithout Driver |
| Signalschnittstelle | LVDS (4 ch, 8/10-bit), 92 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
| LC420WU1-SLA2 | LG Display | 42 | 1920×1080 |
| LC420WUD-SAB1 | LG Display | 42 | 1920×1080 |
| LC420WUD-SBT1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SAB1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SBC1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SCV1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SDP1 | LG Display | 42 | 1920×1080 |
| LC420WUF-SCA2 | LG Display | 42 | 1920×1080 |
| LC420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LC420WUN-SCB1 | LG Display | 42 | 1920×1080 |
| LC320WXN-SCA4 | LG Display | 31.5 | 1366×768 |
| LC420DUK-SGP1 | LG Display | 42 | 1920×1080 |
| LC600DUK-SGK1 | LG Display | 60 | 1920×1080 |
| LK315T3LA57 | SHARP | 31.5 | 1366×768 |
| LTA320HJ06 | Samsung | 31.5 | 1920×1080 |
| MT2751A01-1 | CSOT | 27.5 | 1366×768 |
| T260XVN01.0 | AUO | 26.0 | 1366×768 |
| T260XW05 V0 | AUO | 26.0 | 1366×768 |
| T315HW04 VD | AUO | 31.5 | 1920×1080 |
| T645HW05 V0 | AUO | 65 | 1920×1080 |
