| Artikelnummer | LC370W01-A6 |
| Marke | LG Display |
| Größe | 37 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 600:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | LG.Philips LCD |
| Panel-Modell | LC370W01-A6 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 37 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | S-IPS, Normally Black, Transmissive |
| aktiver Bereich | 819.6×460.8 mm |
| Umriss | 877×516.8 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 8/8 (Typ.)(Tr/Td); 16 (Typ.)(G to G) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 16 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
| LC370EUN-SDV2 | LG Display | 37 | 1920×1080 |
| LC370EUN-SEM2 | LG Display | 36.5 | 1920×1080 |
| LC370EUS-SDS1 | LG Display | 36.5 | 1920×1080 |
| LC370W01-A6 | LG Display | 37 | 1366×768 |
| LC370WU3-SLA1 | LG Display | 37 | 1920×1080 |
| LC370WUE-SBB2 | LG Display | 37 | 1920×1080 |
| LC370WUE-SCA1 | LG Display | 37 | 1920×1080 |
| LC370WUN-SAB1 | LG Display | 37 | 1920×1080 |
| LC370WX1-SL01 | LG Display | 37 | 1366×768 |
| LC370WXE-SBV1 | LG Display | 37 | 1366×768 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC215EUN-SCA1 | LG Display | 21.5 | 1920×1080 |
| LC420EUN-SFF1 | LG Display | 42 | 1920×1080 |
| LTA220W1-L01 | Samsung | 22.0 | 1280×720 |
| T315XW04 V0 | AUO | 31.5 | 1366×768 |
| T370HW03 VG | AUO | 37 | 1920×1080 |
| T400XW01 V1 | AUO | 40 | 1366×768 |
| T420HVN04.0 CELL | AUO | 42 | 1920×1080 |
| T420HW09 V2 | AUO | 42 | 1920×1080 |
| V400H1-L11 | Innolux | 40 | 1920×1080 |
