| Artikelnummer | LC315TU3A |
| Marke | PANDA |
| Größe | 31.5 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 5000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | LVDS |
| Panel-Marke | PANDA |
| Panel-Modell | LC315TU3A |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 31.5 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | UV2A, Normally Black, Transmissive |
| aktiver Bereich | 697.685×392.256 mm |
| Umriss | 715.7×455.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Glastiefe | 0.70+0.70 mm |
| Kontrastverhältnis | 5000:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC) |
| Reaktionszeit | 7 (Typ.)(G to G) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
