| Artikelnummer | HV320FHB-N10 |
| Marke | BOE |
| Größe | 31.5 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 1200:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | LVDS |
| Panel-Marke | BOE |
| Panel-Modell | HV320FHB-N10 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 31.5 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | ADSDS, Normally Black, Transmissive |
| aktiver Bereich | 698.4×392.85 mm |
| Umriss | 708.4×405.4 mm |
| Oberfläche | Antiglare (Haze 1%) |
| Glastiefe | 0.50+0.50 mm |
| Durchlässigkeit | 5.0% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 1200:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 8 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
