| Artikelnummer | G084SN05 V5 |
| Marke | AUO |
| Größe | 8.4 |
| Anwendung | IA |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog + Digital |
| Panel-Marke | AUO |
| Panel-Modell | G084SN05 V5 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.4 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 170.4×127.8 mm |
| Umriss | 203×142.5×12.7 mm |
| Oberfläche | |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 10/25 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | Analog RGB + TTL (1 ch, 6-bit), 45 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
