| Artikelnummer | DLC1210EIG |
| Marke | Other |
| Größe | 12.1 |
| Anwendung | CNS |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 600 |
| CR | 600:1 |
| Farben | 262K/16.2M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | DLC |
| Panel-Modell | DLC1210EIG |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 12.1 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 245.76×184.32 mm |
| Umriss | 260.5×204×8.9 mm |
| Oberfläche | |
| Helligkeit | 600 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K/16.2M (6-bit / 6-bit + FRC), CIE193163% |
| Reaktionszeit | 5/11 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6/8-bit), 20 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(VCC) |
| Anwendung | CNS |
