| Artikelnummer | CLAA215FA04 |
| Marke | CPT |
| Größe | 21.5 |
| Anwendung | DMPC |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CPT |
| Panel-Modell | CLAA215FA04 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 21.5 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 476.64×268.11 mm |
| Umriss | 495.6×292.2×10.35 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193168% |
| Reaktionszeit | 5 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 10S8P×2CNWLEDWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
| CLAA215FA01 | CPT | 21.5 | 1920×1080 |
| CLAA215FA04 | CPT | 21.5 | 1920×1080 |
| CLAA215FA04 V4 | CPT | 21.5 | 1920×1080 |
| CLAA220WA01 | CPT | 21.6 | 1680×1050 |
| CLAA260WU09 | CPT | 25.5 | 1920×1200 |
| CLAA260WU09M | CPT | 25.5 | 1920×1200 |
| LC215DTCA | PANDA | 21.5 | 1920×1080 |
| LC215EUE-TEA1 | LG Display | 21.5 | 1920×1080 |
| M215HGE-L10 | Innolux | 21.5 | 1920×1080 |
| MT215DW01 V.0 | Innolux | 21.5 | 1920×1080 |
| LC215EUE-TEA1 | LG Display | 21.5 | 1920×1080 |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LM185WH1-TLH1 | LG Display | 18.5 | 1366×768 |
| LM240WU5-SLA4 | LG Display | 24.0 | 1920×1200 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| MV215FHM-N30 | BOE | 21.5 | 1920×1080 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| TX38D14VC0CAA | KOE | 15.0 | 1024×768 |
