| Artikelnummer | CLAA154WP05A |
| Marke | CPT |
| Größe | 15.4 |
| Anwendung | NBPC |
| Auflösung | 1440×900 |
| Komposition | LCM |
| Helligkeit | 185 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | CPT |
| Panel-Modell | CLAA154WP05A 8 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.4 inch |
| Auflösung | 1440(RGB)×900 , WXGA+ |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 331.56×207.225 mm |
| Umriss | 344×222×6.2 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Helligkeit | 185 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 4/6 (Typ.)(Tr/Td) |
| Blickwinkel | 40/40/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| CLAA150PB03 | CPT | 15.0 | 1400×1050 |
| CLAA150XA03 | CPT | 15.0 | 1024×768 |
| CLAA150XM05 | CPT | 15.0 | 1024×768 |
| CLAA150XP03 | CPT | 15.0 | 1024×768 |
| CLAA150XP06CW | CPT | 15.0 | 1024×768 |
| CLAA154WA05A | CPT | 15.4 | 1280×800 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| CLAA154WP05A | CPT | 15.4 | 1440×900 |
| CLAA156WA12 | CPT | 15.6 | 1366×768 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B140XTN01.3 | AUO | 14.0 | 1366×768 |
| B141XG14 V1 | AUO | 14.1 | 1024×768 |
| HT140WXB-100 | BOE | 14.0 | 1366×768 |
| LTD133KX2S | TOSHIBA | 13.3 | 1280×800 |
| LTN121AT01-001 | Samsung | 12.1 | 1280×800 |
| LTN156AT23-W01 | Samsung | 15.6 | 1366×768 |
| LTN170X2-L02 | Samsung | 17.0 | 1440×900 |
| LTN173HT02-D02 | Samsung | 17.3 | 1920×1080 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
