| Artikelnummer | AM480272H3TMQW-TW2H |
| Marke | AMPIRE |
| Größe | 4.3 |
| Anwendung | IA |
| Auflösung | 480×272 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 250:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU |
| Panel-Marke | AMPIRE |
| Panel-Modell | AM480272H3TMQW-TW2H |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 4.3 inch |
| Auflösung | 480(RGB)×272 , WQVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 95.04×53.856 mm |
| Umriss | 105.5×67.2×7.91 mm |
| Oberfläche | |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 65K/262K |
| Reaktionszeit | 15/35 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 7S1PWLEDWithout Driver |
| Signalschnittstelle | 8/9/16/18-bit 6800/8080 parallel, 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
